Aluminium Waterproof Tape
Aluminium Waterproof Tape is a heavy-duty, weather-resistant foil tape with a thick, self-adhesive backing. It instantly creates a permanent, watertight seal on roofs, construction joints, and HVAC systems.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Introduction
Aluminium Waterproof Tape is a heavy-duty, weather-resistant foil tape with a thick, self-adhesive backing. It instantly creates a permanent, watertight seal on roofs, construction joints, and HVAC systems.
Product Specifications
|
Parameter |
Standard Value |
Customization Range |
Test Method |
|
Backing Material |
Pure Aluminium Foil / PET-reinforced Al Foil |
30 um - 150 um Foil |
Micrometer |
|
Adhesive Compound |
Premium Synthetic Butyl Rubber |
Bitumen / Specialized Hot-Melt |
- |
|
Total Thickness |
1.0 mm - 1.5 mm |
0.5 mm - 3.0 mm |
ASTM D3652 |
|
Peel Adhesion (to Steel) |
>= 25 N/25mm |
20 N - 40 N/25mm |
ASTM D3330 |
|
Tensile Strength |
>= 45 N/cm |
30 N - 80 N/cm |
ASTM D3759 |
|
Elongation at Break |
15% - 25% |
Up to 50% (Reinforced options) |
ASTM D3759 |
|
Service Temperature |
-40 deg C to 100 deg C (-40 deg F to 212 deg F) |
Up to 120 deg C (248 deg F) for HVAC |
Oven / Freezer Test |
|
Water Vapor Permeability |
0.0 g/m2 / 24h (Absolute Barrier) |
Completely Impermeable |
ASTM E96 |
Applications
Roofing & Flashing Insulation: Sealing roof ridges, valleys, chimneys, skylights, and parapet walls against heavy rainwater penetration.
HVAC Ductwork & Ventilation: Sealing high-pressure air ducts, thermal insulation jackets, and vapor barriers in commercial HVAC installations.
Window & Door Pan Sealing: Water-proofing building envelopes, sills, and framing joints prior to exterior cladding installation.
Pipe & Tank Repair: Patching leaks and providing external anti-corrosion wrapping for metal pipe networks and storage tanks.
Why Choose Us
High-Volume Capacity: 3 advanced production lines yield 600,000+ sqm monthly, ensuring stable, on-time delivery for Tier-1 distributors.
Low Commercial MOQs: Reduce capital risk with a low minimum order of just 2,000 rolls per standard size for direct import trials.
Certified Manufacturing: Certified under ISO 9001:2015 and ISO 14001:2015 standards, ensuring predictable, high-tier consistency.
Packaging & Logistics
Export Packaging: Rolls are individually shrink-wrapped with desiccant in 5-layer master cartons to prevent core collapse.
Seaworthy Palletization: Secured on plastic or ISPM-15 fumigated wooden pallets with rigid edge protection for maritime transit.
Global Fulfillment: Fully compliant with Western import docs, offering flexible shipping under FOB, CIF, DDU, or DDP terms.
Quality Assurance
Building Compliance: Conforms to CE Mark (EN 13969) waterproofing criteria and maintains full EU REACH and RoHS certifications.
Rigorous Testing: Every batch undergoes dynamic peel testing, aging oven simulations, and water immersion before shipping.
Batch Traceability: ERP-linked barcoding traces every roll back to its raw butyl resin batch, aluminum coil lot, and production timeline.
After-Sales Support
12-Month Warranty: 100% financial credit or batch replacement for structural defects (e.g., adhesive separation, delamination) within 12 months.
Fast Claim Resolution: Initial assessment within 24 hours and a formal 8D corrective report within 5 business days for any field issues.
FAQ
Q: Can your aluminium tape be applied directly to wet surfaces?
A: For optimal mechanical adhesion, surfaces should ideally be dry, clean, and free of loose debris. However, our premium butyl formulation features excellent displace-tack and can form a secure bond over damp surfaces when applied with firm, mechanical roller pressure.
Q: How does the tape perform under extended exposure to UV and extreme summer heat?
A: The pure aluminium foil backing reflects over 95% of UV radiation and thermal energy, acting as a shield for the adhesive underneath. The inner butyl rubber compound is cross-linked to resist degradation, melting, or sliding at temperatures up to 100°C (212°F) ensuring compliance with standard commercial roofing heat-resistance codes.
Q: Does your adhesive contain volatile organic solvents that could affect indoor air quality?
A: No. Our adhesive is a 100% solid butyl rubber compound containing zero solvents, volatile organic compounds (VOCs), or hazardous air pollutants. It is completely odorless and safe for indoor HVAC duct systems.
Q: What certificates can you provide to clear European and North American customs?
A: We provide comprehensive documentation packets including CE compliance reports, REACH declarations, RoHS certification, and complete Safety Data Sheets (SDS) authored to global GHS standards.
Q: What is your typical production turnaround for a customized OEM order?
A: For a standard 20ft container with custom branded packaging or custom printed release liners, our turnaround time is 25 days. Re-orders with existing artwork can be expedited and shipped within 15–20 days.
Q: Are we able to request custom roll dimensions for specific building projects?
A: Yes. We can slit the Master Rolls to any specific width from 20mm up to 1000mm, with custom roll lengths tailored to your market's standard retail or industrial packaging dimensions. Free pre-production evaluation samples are available.
